Belimo CM24-MPL-L

Communicative damper actuator Current reduction in rest position Constant, load-independent running time Adaptable setting range Mechanical angle of rotation limiter and position indication Torque motor 2 Nm Nominal voltage AC/DC 24 V Nominal voltage frequency 50/60 Hz Power consumption in operation 1 W Power consumption in rest position 0.5 W Power consumption for wire sizing 1.5 VA Control communicative Communication MP-Bus Running time motor 75 s / 90° Direction of motion motor counter-clockwise rotation (ccw) Angle of rotation 0...287.5° Manual override with magnet Mechanical interface Universal shaft clamp 6...12.7 mm Electrical connection Cable 1 m PVC Degree of protection IEC/EN IP54 Protection class IEC/EN III, Safety Extra-Low Voltage (SELV) Manufacturer Belimo Type CM24-MPL-L
