S+S Surface contact / tube contact tempe­rature sensor - ALTF2 NTC1,8K

S+S Surface Contact / Tube Contact Temperature Sensor - ALTF2 NTC1,8K

Discover the innovative S+S Surface Contact / Tube Contact Temperature Sensor - ALTF2 NTC1,8K from S+S Regeltechnik GmbH. This high-quality thermowell features an NTC 1.8kOhm sensor, designed for precise temperature measurement in a variety of applications.

Product Attributes

• Sensor: NTC 1.8kOhm
• Measurement Range: -30 to +110 °C
• Ambient Humidity: < 95% RH, non-condensing air
• Housing: UV-resistant plastic, made of Polyamide, 30% glass bead reinforced, with quick-release screws (slotted / cross-slot combination), Traffic White color (similar to RAL 9016)
• Dimensions: 72 x 64 x 37.8 mm (Type 1)
• Cable Gland: M16 x 1.5; with strain relief, replaceable, maximum inner diameter 10.4 mm
• Process Connection: Endless tension band with metal lock (included in delivery)
• Protection Rating: IP 65 (according to EN 60 529) Housing tested, TÜV SÜD, Report No. 713139052 (Type 1)
• EAN: 4251325600147

Benefits and Features

The THERMASGARD® ALTF2 sensor is a versatile thermowell ideal for measuring surface temperatures of solid objects, offering precise and reliable temperature readings for efficient monitoring and control. The durable plastic housing ensures longevity and protection against environmental elements, while the quick-release screws allow for easy installation and maintenance. With its passive output and reliable NTC sensor, this sensor is a dependable solution for various temperature monitoring applications.

The ALTF2 sensor is specifically designed for temperature sensing in pipes, ensuring accurate temperature measurements of flowing media such as water within heating or cooling systems. Its robust construction and IP65 protection rating make it suitable for harsh industrial environments, providing peace of mind and consistent performance.

Technical Data

For the most up-to-date technical specifications and detailed product information, refer to the official product datasheet or the manufacturer's website. Stay informed with the latest technical data to maximize the performance and efficiency of your temperature monitoring systems.
