S+S Outside tempe­rature sensor / wet room tempe­rature sensor - ATF1 Ni1000

S+S Outside Temperature Sensor / Wet Room Temperature Sensor - ATF1 Ni1000 Overview

The S+S Outside Temperature Sensor / Wet Room Temperature Sensor - ATF1 Ni1000 by S+S Regeltechnik GmbH is a versatile sensor designed for accurate temperature monitoring in various environments. This external sensor features a durable plastic housing with quick-release screws, making it ideal for outdoor installations, industrial settings, and agricultural applications.

Key Features

• Sensor Type: Ni1000, DIN EN 43760, Class B
• Temperature Range: -50°C to +90°C
• Allowed Air Humidity: < 95% RH, non-condensing air
• Material: UV-resistant plastic housing made of Polyamide
• Dimensions: 72 x 64 x 37.8 mm (Type 1)
• Cable Gland: M16 x 1.5, with strain relief, replaceable, max. inner diameter 10.4 mm
• Protection Class: IP67 (according to EN 60529) housing tested by TÜV SÜD
• Accessory: Sun and ball protection shields available for use in direct sunlight

Benefits for Customers

The ATF1 Ni1000 sensor provides accurate temperature readings for outdoor and wet room environments, ensuring reliable performance even in challenging conditions. Its sturdy construction and UV-resistant material ensure durability and longevity, making it a cost-effective solution for various temperature monitoring applications.

Technical Specifications

• Sensor Type: Ni1000
• Temperature Range: -50°C to +90°C
• Allowed Air Humidity: < 95% RH
• Material: UV-resistant Polyamide
• Dimensions: 72 x 64 x 37.8 mm
• Cable Gland: M16 x 1.5
• Protection Class: IP67
