S+S Outdoor motion sensor - ABWF-W

S+S Outdoor Motion Sensor - ABWF-W Overview

The S+S Outdoor Motion Sensor - ABWF-W from S+S Regeltechnik GmbH is a state-of-the-art motion detector that efficiently detects the presence of individuals and movements. It is designed for monitoring, state detection, and movement-based control of room functions, such as temperature reduction in unused spaces. With a wide application range in corridors, outdoor areas, industrial halls, offices, and residential or commercial spaces, this sensor offers high performance and reliability.

Advanced Sensor Technology

The motion sensor features a 110° and 360° detection angle, ensuring comprehensive coverage. Its patented lens system with 20 individual lenses minimizes blind spots, guaranteeing accurate detection of small movements even at a distance of 10 meters. The sensor works by detecting changes in infrared radiation, specifically heat radiation resulting from movements of individuals or objects. This technology makes it highly effective in detecting people based on their body heat radiation.

Technical Specifications

- Operating Voltage: 24 V AC (± 20%) and 15…36 V DC
- Sensor Type: Infrared motion sensor
- Output: Without/With motion + presence, potential-free changeover contact (24 V), 1 A resistive load
- Housing: UV-resistant plastic, polyamide material, 30% glass ball reinforced, with quick-release screws (slotted/cross-slot combination), Traffic White color (similar to RAL 9016)
- Dimensions: 72 x 64 x 37.8 mm
- Mounting: Surface-mounted
- Cable Gland: M 16 x 1.5; with strain relief, replaceable, max. inner diameter 10.4 mm
- Protection Rating: IP 65 (per EN 60 529) housing tested, TÜV Süd, Report No. 713139052 (Type 1)

Benefits and Performance

The S+S Outdoor Motion Sensor - ABWF-W provides an efficient solution for monitoring movements and presence in various environments. With its advanced technology and accurate detection capabilities, it ensures reliable performance for temperature control and security purposes. The sensor's compact design and easy installation make it a practical choice for both indoor and outdoor applications.
