S+S Room motion sensor / presence detector and light sensor - RBWF-LF-I

S+S Room Motion Sensor and Light Sensor - RBWF-LF-I

Enhance your building automation system with the innovative S+S Room Motion Sensor and Light Sensor - RBWF-LF-I from S+S Regeltechnik GmbH. This versatile device combines a presence detector, motion sensor, and light sensor with a diffuser, enabling comprehensive monitoring of movements, light intensity, presence, and various conditions.

Key Features and Benefits

Efficient Lighting Control: The RBWF/LF provides a signal output of 0-10 V or 4-20 mA for brightness and a switch contact output for motion detection, allowing for precise control of lighting in various settings.

Multi-Functional Use: Ideal for use in building automation, corridors, workplaces, industrial halls, offices, and commercial spaces to regulate lighting based on demand, such as for sun protection control, daylight-dependent constant light regulation, and energy conservation.

Easy Installation: The sensor can be easily mounted on a wall or a junction box, facilitating flexible deployment in different locations.

Technical Specifications

Power Supply: 15-36 V DC

Sensors: Infrared motion sensor, light sensor with diffuser

Motion Sensor Output: Potential-free changeover contact (24 V), 1 A resistive load

Light Sensor Output: 4-20 mA

Light Sensor Range: Selectable via DIP switch with multiple ranges from 0-500 Lux to 20 kLux

Housing: ABS plastic in Pure White (similar to RAL 9010) color

Dimensions: 85 x 85 x 27 mm

Mounting: Wall mounting or on a junction box, suitable for vertical or horizontal mounting with cable entry at the back

Protection Rating: IP30 (according to EN 60529)

Current Technical Data

You can find the most up-to-date technical data for the S+S Room Motion Sensor and Light Sensor - RBWF-LF-I by visiting the manufacturer's official website or consulting authorized dealers.
