S+S Ceiling Built-In Motion Sensor - DBWF-W

The S+S Ceiling built-in motion sensor - DBWF-W from the manufacturer S+S Regeltechnik GmbH is a versatile and efficient solution for detecting the presence of individuals and movements. Equipped with a switch contact (changeover), this motion sensor is designed for monitoring, state detection, and motion-dependent control of room functions, such as temperature reduction in unused areas.

Key Features

• Detection Angle: 110° and 360° coverage for comprehensive motion sensing
• Patented Lens System: 20 individual lenses minimize blind spots and ensure accurate motion detection even at distances of up to 10 meters
• Output: Potential-free changeover contact (24 V), 1A resistive load
• Material: UV-resistant polyamide housing with quick-release screws for easy installation
• Power Supply: 24 V AC (± 20%) and 15-36 V DC
• Protection: IP 65-rated housing for durability and reliability

Applications

Perfect for installation in suspended ceilings of corridors, offices, residential, and commercial spaces. The separate housing of the converter ensures optimal performance.

Technical Details

• Dimensions: 72 x 64 x 37.8 mm (Type 1)
• Mounting: Sensor installation in the suspended ceiling with a ceiling cut-out of Ø=30 mm
• Flexible Connection: Sensor cable - PVC, LiYY, 4 x 0.14 mm², approx. 2 meters in length
• Cable Gland: M 16 x 1.5 with strain relief, replaceable, max. inner diameter of 10.4 mm
• Certification: IP 65 rated housing, TÜV SÜD certified

This ceiling motion sensor offers precise motion detection, easy installation in suspended ceilings, and reliable performance for various applications. The robust construction and advanced features make it an ideal choice for enhancing security and energy efficiency in your space.
