S+S Ceiling built-in motion sensor - DBWF-C

S+S Ceiling Built-In Motion Sensor - DBWF-C Overview

Welcome to our product spotlight featuring the innovative S+S Ceiling Built-In Motion Sensor - DBWF-C from the reputable Hersteller. This advanced sensor is designed to detect movements and presence of individuals, enhancing room automation and control functionalities.

Key Features and Benefits

• 360° and 110° detection angles for comprehensive coverage
• Patented lens system with 20 individual lenses for precise motion detection
• Potential-free contact output for easy integration
• Compact design for seamless integration into various ceiling types
• Triggers movement-dependent automation, such as temperature adjustment in unused spaces

Technical Specifications

• Voltage: 24 V AC (± 20%) and 15-36 V DC
• Sensor Type: Infrared motion sensor
• Output: Potential-free contact, signal relay, max. 24 V / 0.5 A
• Housing Material: PVC plastic in black color
• Connection Head: White Polycarbonate (PC), paintable, detachable
• Dimensions: 55 x 20 x 15 mm compact form
• Mounting: Ceiling cut-out Ø = 30 mm, Cover Ø = < 35 mm
• Protection Class: IP 20 (according to EN 60 529)
• EAN: 4251325612973

Current Technical Data

Please refer to the manufacturer's website or official dealers for the most up-to-date technical specifications of the S+S Ceiling Built-In Motion Sensor - DBWF-C.
