ZIEHL-ABEGG Frequency inverter FXET6AMQ - Fcontrol, 6A

ZIEHL-ABEGG Frequency Inverter FXET6AMQ - Fcontrol, 6A

The ZIEHL-ABEGG Frequency Inverter FXET6AMQ - Fcontrol, 6A offers exceptional benefits for various applications. With an integrated all-pole effective sinus filter, this frequency inverter ensures a sinusoidal output voltage comparable to the normal power supply grid. As a result, reliable, demand-oriented, and energy-saving control of asynchronous motors is achieved without the need for specific measures required by standard frequency converters.

Advantages of Fcontrol Frequency Inverter:

• Operation without shielded motor cables
• No restriction on cable length
• Operation without electromagnetic motor noise, ideal for noise-sensitive areas
• No risk to motors as they are supplied with sinusoidal voltage, corresponding to the network voltage

Fcontrol frequency inverters are particularly valuable when multiple motors or fans are operated in parallel, often involving long cable lengths. The Fcontrol allows easy parallel connection of motors with the use of unshielded cables.

The Fcontrol Universal devices are well-suited for applications in refrigeration, air conditioning, agriculture, general ventilation tasks, and cleanroom technology. Quick commissioning is facilitated by selecting pre-programmed operating modes for typical applications in these fields.

Features and Characteristics:

• Integrated all-pole effective sinus filter generating sinusoidal output voltage
• Integrated PFC (Power Factor Controller) for active power factor adjustment
• Integrated main switch with bypass function for various operating modes
• LC multifunction display with clear text display for easy operation
• Advanced programming options for specific settings, e.g., minimum and maximum speed limits, multi-stage operation
• Two analog inputs for sensors or setpoint signals

Norm Conformity:

• EMI according to EN 61000-6-3 standards for residential areas
• EMC according to EN 61000-6-2 standards for industrial environments

For technical data and precise specifications of the ZIEHL-ABEGG Frequency Inverter FXET6AMQ - Fcontrol, 6A, refer to reputable sources such as the manufacturer's official website or data sheets. Ensure to find the most up-to-date technical information for accurate product details and performance metrics.
